PEEK板棒管片等型材规格



PEEK棒材规格表
序号直径mm

米重kg weight per meter

PEEK5600GPEEK5600CF30PEEK5600GF30PEEK5600LF30
1φ50.030.040.040.04
2φ60.050.050.060.06
3φ80.060.070.080.08
4φ100.110.130.140.13
5φ120.160.170.190.18
6φ150.250.270.290.28
7φ160.270.280.310.29
8φ180.360.380.420.39
9φ200.450.450.530.51
10φ220.530.560.610.58
11φ250.670.650.760.72
12φ26.70.760.80.880.83
13φ280.840.921.030.95
14φ300.940.971.181.02
15φ321.071.121.291.22
16φ351.351.341.421.35
17φ381.521.661.811.71
18φ401.711.762.022.02
19φ421.912.052.222.11
20φ452.132.322.562.39
21φ482.522.622.852.71
22φ502.662.813.133.14
23φ532.953.153.453.26
24φ553.143.643.723.15
25φ603.954.164.64.21
26φ654.374.765.424.37
27φ705.515.616.235.82
28φ755.996.366.926.54
29φ807.087.617.947.82
30φ857.678.228.818.43
31φ909.259.3910.219.67
32φ959.1610.1311.0810.42
33φ96.59.6610.2811.1710.64
34φ10010.7310.8112.0911.44
35φ11012.9312.9114.5913.57
36φ11513.5314.7816.0615.22
37φ12015.4416.4217.6216.67
38φ12516.1817.2118.7317.74
39φ13020.0819.2121.8219.57
40φ14020.5521.6623.7822.89
41φ15023.8126.2927.6426.36
42φ16026.8529.8133.7130.67
43φ16529.0130.1833.8931.02
44φ17030.2232.4935.0433.43
45φ18033.9935.9338.9436.88
46φ19037.86///
47φ20043.26///
48φ22050.79///
49φ25065.51///

注:棒材具体尺寸规格及重量以实际发货为准,上述数据仅供参考
